QLS 401 GREASE PUMP 24V + LOW LEVEL SIGNAL

SKU
1042286

Lincoln QLS 401 Grease pump 1 Liter 24V with low level signal

  • Provided with a progressive divider with 1 to 12 lubrication points
  • Suitable for grease to NLGI 2
  • Supply voltage 24VDC
  • Maximum pressure 205 bar
  • Protection class IP65
  • Temperature -25 to 70°C

For connecting the tubes on the manifold, the right couplers and closure plugs should be ordered. See related products.

Stock quantity: 1
€1,160.83
Verzending door DHL

Orders placed on workdays before 15:30 will be shipped the same day.


Lincoln Quicklub pump QLS 401
Model  P401-SSV12-V- 24DC-1XL-2A1.1
For lubricant Grease to class NLGI-2
Manifold SSV 12
Supply voltage 24V DC
Reservoir capacity 1 Liter
Low level signal Yes

Electrical connection

Left side, power supply

Right side, low level signal and error message

Connector(s) Square Form A DIN 175301-803
Timer  Yes
Lincoln Reference P40161411110
More Information
Power supply24V
