P653S OILPUMP 4L 24V + TIMER + LOW LEVEL SIGNAL
P653S OILPUMP 4L 24V + TIMER + LOW LEVEL SIGNAL
P653S OILPUMP 4L 24V + TIMER + LOW LEVEL SIGNAL P653S OILPUMP 4L 24V + TIMER + LOW LEVEL SIGNAL
{{ active + 1 }} / {{ images.length }}

P653S OILPUMP 4L 24V + TIMER + LOW LEVEL SIGNAL

Backordered
1 in stock
€1,858.23
Excl. vat

Centro-Matic single-line pump suitable for use with Centro-Matic injectors type SL-41, 42, 43 & 44

  • Suitable for oil and liquid grease up to NLGI 00
  • Standard fitted with 3 pump elements K7, with a total output of 24.6 cc/min.
  • Pump element connection 1/4"G
  • Protection class IP 6K9K (NEMA 4X)
  • Temperature -40 to 70°C
  • Monitoring / pump time 30 minutes
  • Maximum output per pump cycle 738 cc
Specifications
  • SKU 1041535
  • Brand Lincoln
  • Pump type P653
  • Model P653S- 4YLBO-3Z7-24-1A7.16-AS22-SE
  • Lincoln Reference 645-41198-9
  • Pump Electric
  • Pump element(s)
  • Power supply 24V
  • Reservoir type Plastic with screw cap
  • Maximum pressure (bar) 320
  • Material to be pumped Oil
  • Suitable for grease up to class NLGI-00
  • Connector Bajonet 7 polig met 10 meter kabel
  • Electric connections Linkerzijde, Voeding, Laag niveau controle, Foutmelding & handbediening met verlichte drukknop
  • Country of origin CZ
  • HS Code 84135069
