With the M08 microprocessor timer the pump's pause time can be set in hours. After the selected pause time elapses, the pump starts automatically and continues to run until a complete lubrication cycle has been completed on the progressive distributor on which the cycle sensor is mounted. The pump then returns to pause mode.
The pump has a maximum run time of 5 minutes (monitoring time). Within this time the sensor must send a detection signal. If this does not occur within the set monitoring time, the pump stops automatically and a fault is generated.
We recommend using a pressure relief valve for each pump element. Click here for an overview of pressure relief valves.
See related products for a matching cycle sensor.
Specifications
- SKU 1042845
- HS Code 84135069
- Country of origin CZ
- Lincoln Reference 644-41312-9
- Maximum pressure (bar) 350
- Pump Electric
- Model P203_E-_4XL__-600-24-006F00N0-M08A
- Connector Bajonet 7/5 polig met 10 meter kabel
- Electric connections Linkerzijde, Voeding, Laag niveau controle & handbediening met verlichte drukknop Rechterzijde, Bajonet 4 polig voor aansluiting sensor(en) van verdeler(s)
- Model (old) P203- 4XL -1K6-24-2A6.15-M08
- Brand Lincoln
- Pump type P203
- Suitable for grease up to class NLGI-2
- Reservoir type Plastic, closed
- Power supply 24V
- Material to be pumped Grease
- Pump element(s) 1 x K6
