P203 GREASE PUMP 2L 24V + TIMER

SKU
1041032

Lincoln P203 Grease pump 2 Liter 24V with Timer

  • Suitable for grease to NLGI 2
  • Includes Pump element K6 with an output of 2.8cc/min. Can be extended tot a maximum of 3 pump elements, see related products.
  • Connection pump element 1/4"G
  • Supply voltage 24VDC
  • Maximum pressure 350 bar
  • Protection class IP65
  • Temperature -25 to 75°C

We recommend using a pressure relief valve for each pump element. Click here for an overview of pressure relief valves.

Stock quantity: 3
€1,107.27
Lincoln

Orders placed on workdays before 15:30 will be shipped the same day.


Lincoln Quicklub pump P203
Model P203_E-_2XN__-600-24-A1000000-V10A
Model (old) P203- 2XN  -1K6-24-1A1.01-V10
Reservoir size 2 Liters
For lubricant Grease to class NLGI-2
Low level signal No
Reservoir type Standard / Closed
Pump elements 1 x K6
Supply voltage 24V DC

Electrical connection

Left side, power supply

Right side, none

Connector Square Form A DIN 175301-803
Timer  No
Lincoln Reference 644-40563-2



More Information
ManufacturerLincoln
Reservoir2 L
TimerJa
Power supply24 V
Low level signalNo
