We recommend using a pressure relief valve for each outlet. Click here for an overview of pressure relief valves.
Specifications
- SKU 1040985
- HS Code 84135069
- Country of origin CZ
- Lincoln Reference 644-37424-1
- Maximum pressure (bar) 350
- Pump Electric
- Model P203_E-_2XN__-600-24-AA000000-V10A
- Connector Vierkant Form A DIN 175301-803 met 10 meter kabel
- Electric connections Linkerzijde, Voeding | Rechterzijde, Geen
- Model (old) P203- 2XN -1K6-24-1A1.10-V10
- Brand Lincoln
- Pump type P203
- Suitable for grease up to class NLGI-2
- Reservoir type Plastic, closed
- Power supply 24V
- Material to be pumped Grease
- Pump element(s) 1 x K6
Below you will find the downloads and documents. These are manuals or pictures that explain the product.
Data Sheet
Manuals
