Technical specifications
- Pressure ratio 50:1
- Length of pump tube 695mm
- Maximum output at free range 1311cc/min
- Output per cycle 5.7cc
- Output at 60 cycles per minute 342cc
- Maximum air pressure 10.0 bar
- Maximum outgoing pressure 500 bar
- Air connection 1/4NPT
- Outlet 1/4NPT
Specifications
- SKU 1100235
- HS Code 84135069
- Land van herkomst US
- Lincoln Referentie 82050
- Pomp soort Pneumatic
- Merk Lincoln
- Te verpompen materiaal Grease
Below you will find the downloads and documents. These are manuals or pictures that explain the product.
Manuals
Data Sheet
