Technical specifications
- Pressure ratio 50:1
- Length pump tube 862mm
- Maximum output at free range 1311cc/min
- Output per cycle 5.7cc
- Output at 60 cycle per minute 342cc
- Maximum airpressure 10.0 bar
- Maximum outgoing pressure 500 bar
- Air connection 1/4NPT
- Outlet 1/4NPT
Specifications
- SKU 1100240
- HS Code 84135069
- Land van herkomst US
- Lincoln Referentie 82054
- Pomp soort Pneumatic
- Merk Lincoln
- Te verpompen materiaal Grease
Below you will find the downloads and documents. These are manuals or pictures that explain the product.
Manuals
